Input Range
2.5 V to 5.5 V
Fixed Output Constant Current Limit
GLF2313 B: 2.0 A Min
Low RON
56 mΩ Typ. @ 5.0 VIN
Ultra-Low IQ
20 uA Typ. @ 5.0 VIN
Ultra-Low ISD
50 nA Typ. @ 5.0 VIN
Under Voltage Lockout Protection
Output Voltage Slew Rate Controlled
True Reverse Current Blocking Protection
Short Circuit Protection
Deglitched Fault Flag Indication
Integrated Output Discharge Switch
Thermal Shutdown Protection
IEC 62368-1:2018 CB Certification No. FI-52066
The GLF2310, GLF2311, GLF2313 and GLF2321 are an advanced technology fully integrated power switch for applications required for precision output current limiting. The GLF2310, GLF2311, GLF2313 and GLF2321 feature also various protection functions such as under voltage lockout, true reverse current blocking (TRCB), short circuit protection, and thermal shutdown.
The GLF2310, GLF2311, GLF2313 and GLF2321 provide a built-in output voltage slew rate control to limit the inrush current and voltage surges. The FLGB output pin can be used to send a signal of fault events to the system controller. The integrated thermal shutdown (TSD) insures complete protection for the switch during output current limit and short circuit conditions. The GLF2310, GLF2311, GLF2313 and GLF2321 are an ideal switch for USB power supply.
